Multi-Layer Steel (MLS) Cylinder Head Gasket 0.92-0.95 mm Thickness for 89 mm Bore Nissan YD25 Engine

  • 1
  • 2

Place of Origin : China

MOQ : 10 pcs

Net Weight : 0.37 kg

Brand Name : YIMI

Gasket Type : Multi-Layer Steel (MLS) – stainless steel with elastomer coating

Delivery Time : 5-8 Work Days

Payment Terms : T/T,

OEM Part Number : 11044-VK502 (also 11044VK502)

Bore Diameter : 89 mm

Combustion Chambers : 4

Supply Ability : 10000 pcs/month

Packaging Details : Neutral Package or as customers’ request

Notches Coding : 2 notches (2 holes)

Price : Negotiable

Compressed Thickness : 0.92 – 0.95 mm (nominal)

Fire Ring Tolerance : 89 mm ±0.03 mm

Certifiion : ISO/TS16949

Model Number : Nissan YD25 2.5 dCi Navara Pathfinder Cabstar

Contact Now

Cylinder Head Gasket 11044-VK502 For Nissan YD25 2.5 dCi

The cylinder head gasket carrying Nissan genuine part number 11044-VK502 (also 11044VK502) seals the interface between the cylinder head and engine block on Nissan's widely used YD25 2.5 dCi diesel engine. It is a direct OE replacement for vehicles such as the Nissan Navara (D22, D40, NP300), Pathfinder R51, Cabstar (F24), Atlas, Hardbody and Urvan, as well as the NP300 pick-up platform.

Technical Specifiions
Part Number: 11044-VK502
Product Name: Cylinder Head Gasket
Car Model: Nissan Navara Pathfinder Cabstar
Engine Model: Nissan YD25 2.5 dCi
Condition: 100% Brand New
Origin: China Mainland
Main Market: Middle East, Asia, Africa, South America, North America & Europe
Multi-Layer Steel (MLS) Cylinder Head Gasket 0.92-0.95 mm Thickness for 89 mm Bore Nissan YD25 Engine
Thickness Coding System

The YD25 uses a multi-layer steel (MLS) head gasket with a notch-based thickness coding system:

Part Number Notches Thickness
11044-VK500 0 notches 0.85-0.90 mm
11044-VK501 1 notch 0.90-0.925 mm
11044-VK502 2 notches 0.92-0.95 mm
11044-VK503 3 notches 0.95-0.975 mm
11044-VK504 4 notches 0.97-1.00 mm
11044-VK505 5 notches 1.00-1.025 mm
Appliions
Chassis / Model Engine Years
Nissan Navara D22 pick-up YD25 (2.5 dCi) 2001-2008
Nissan Navara D40 (EU) YD25 (2.5 dCi) 2005-2010
Nissan Navara NP300 YD25 (2.5 dCi) 2014-present
Nissan Pathfinder R51 YD25 (2.5 dCi) 2005-2014
Nissan Cabstar / Atlas YD25 (2.5 dCi) 2009-2015
Nissan NP300 pick-up YD25 (2.5 D) 2008-2015
Key Features
  • Multi-Layer Steel (MLS) Construction - Withstands high cylinder pressures and thermal loads
  • Precision 89 mm Fire Rings - Ensures gas-tight combustion sealing
  • Two-Notch (0.92-0.95 mm) Thickness - Middle-range option for most appliions
  • Elastomer Coating - No additional sealants required
  • Genuine Nissan OEM - Made to original engineering specifiions
  • ISO 9001 / IATF 16949 Certified - OEM-standard manufacturing quality
Important Installation Note

⚠️ The YD25 uses torque-to-yield (stretch) cylinder head bolts. These are single-use fasteners and must be replaced with new units whenever the cylinder head is removed. Reusing old bolts risks uneven clamping, head gasket failure and cylinder head warping.

Common Failure Symptoms
Symptom Diagnosis
Coolant loss with no visible external leak Coolant escaping past the fire ring into combustion chamber
White/grey steam from exhaust when warm Coolant burning in combustion chamber
Pressure in cooling system when cold Combustion gases entering cooling system
Overflow bottle bubbling at idle Combustion gases entering coolant system
Milky oil residue under filler cap Coolant mixing with engine oil
Packaging & Supply
  • Individual packaging: Sealed anti-static VCI bag, foam-lined carton
  • Carton dimensions: 25 × 20 × 2 cm (10 × 8 × 1 inch)
  • Net weight: Approximately 0.37 kg
  • Master carton: 50 units per export carton
  • Lead time: 3-7 working days for stock orders
  • Minimum order quantity: 1 piece
  • H/S Code: 8484.10
